Horizon HZ7 14' Gooseneck Dump Trailer 7K
| Stock # | 11230 |
| Año | 2026 |
| Marca | Horizon Trailers |
| Numero de Modelo | HZ7 14' x 83" GN |
| Color | Cloud Gray |
| Longitud del piso | 14' |
| Ancho | 83" |
| Altura lateral | 3' |
| GVWR | 15,680 lbs |
| Axle Capacity | 7,000 lbs |
| Ubicación | Springdale, AR |
Código de barras:
3H7GD1421TR011230
Referencia interna:
11230
Standard Trailer Specs
DIMENSIONS -
LENGTH: 14'
SIDE HEIGHT: 3'
BED WIDTH: 83"
BED HEIGHT: 28"
WEIGHT RATINGS
GAWR: 7,000 lbs
GVWR GN: 15,680 lbs
FINISH
PAINT TYPE: Powdercoat
PREP: Steel Grit Blasted
NECK
SPARE: Weld On Spare Tire Mount
FRONT JACKS: Dual Side Wind Spring Loaded Drop Jack Leg (12,000 lbs)
TOOLBOX: Mega Lockable Toolbox Houses Battery & Pump
SAFETY SYSTEM
BREAKAWAY SYSTEM: 2382 Brightway Group Electric Breakaway Kit
SAFETY CHAINS: 3/8" Grade 70 Safety Chain w/Clevis Hook (2 each)
CHASSIS
MAIN FRAME: 8" I-Beam (13 lbs/ft)
STEPS: Side Step On Both Sides
BED
BED WIDTH: 83"
BED HEIGHT: 28"
FLOORING: 7ga. Floor
FRAME: 5" x 5" x 5/16" Angle Iron (10.3 lbs/ft)
CROSSMEMBERS: 3" Channel (3.50 lbs/ft) 16" Spacing
D-RINGS: 4 D Rings Welded Inside Box
DUMP ANGLE: 39° - 49°
REAR
GATE: 2 Way Door
RAMPS: Ramp Pockets w/2 - 6' 4" Heavy Duty Slide In 4" Channel Ramps (5,000 lbs each)
REAR STANDS: Pair Of Rear Stabilizer Stands
SIDES
HEIGHT: 3'
THICKNESS: 10ga.
TYPE: Rounded Steel
TOP RAIL: 3" x 5" x 11ga. Tubing
STAKE POCKETS: 1,5/8" x 3,5/8" (ID) Stake Pockets
HOOKS: 3/8" Round "D" Hooks
FENDERS: 12ga. Diamond Plate Steel Fenders
SAFETY
TARP: Manual Tarp Kit
LIFT SYSTEM/HYDRAULICS
SYSTEM: Hydraulic - Power Up / Gravity Down
PUMP: KTI 12V Hydraulic Pump
CONTROLLER: 14' Control Cable
CYLINDER: 6"x21: Single Push
HOIST CAPACITY: 20,000 lbs
RUNNING GEAR/TIRES
TYPE: Radial Tires
SIZE: ST235/80R16
PLY: 14
RATING: 3,520 lbs
RIMS: 16" Black Mod Wheels
SUSPENSION
AXLE TYPE: 2 - 7k Lippert Electric Brake EZ Lube Spring Axles
BOLT PATTERN: 8 On 6.5"
AXLE COUNT: 2
SUSPENSION TYPE: Spring
AXLE WARRANTY: 6 Year Lippert Spring Axle Warranty
BATTERY AND CHARGING
BATTERY: 1 - Interstate 27 Deep Cycle Battery
CHARGING SYSTEM: 110V Integrated Trickle Charger
WIRING HARNESS: All-Weather Wiring Harness (7-Way RV)
FRAME WIRING: Double Insulated Wiring Harness
LIGHTING
LIGHTS: DOT Approved Tecniq LED Lights
SAFETY
REFLECTIVE TAPE: 3M Dot Compliant Reflective Tape
