Horizon HEH 26' Drive Over Fender Gooseneck Equipment Trailer 10K (23'+3')
Standard Trailer Specs
TRAILER SPECS/DIMENSIONS:
LENGTH: 26'
DECK WIDTH: 102"
DECK HEIGHT: 25"
WEIGHT RATINGS
GAWR: 10,000 lbs
GVWR: 22,400 lbs
UNLOADED VEHICLE WEIGHT: 5,660 lbs
CARRYING CAPACITY: 16,740 lbs
FINISH
PAINT TYPE: Powdercoat
PREP: Steel Grit Blasted
WARRANTY
AXLE WARRANTY: 5 Year Dexter Torsion Axle Warranty
TRAILER WARRANTY: Three (3) Year Frame/One (1) Year Parts Warranty
TONGUE
SPARE: Weld On Spare Tire Mount
COUPLER
STANDARD COUPLER : Adjustable 2-5/16" GN
JACK
FRONT JACK S: 2 Side Wind Spring Loaded Drop Jack Leg (12,000 lbs)
TOOLBOX
TOOLBOX : Mega Lockable Toolbox
SAFETY SYSTEM
BREAKAWAY SYSTEM: 2382 Brightway Group Electric Breakaway Kit
SAFETY CHAINS: 3/8" Grade 70 Safety Chain w/Clevis Hook (2 each)
CHASSIS/FRAME
MAIN FRAME: 10" I-Beam (17 lbs/ft)
DECK/BED
DECK WIDTH: 102"
WIDTH BETWEEN FENDERS: 82"
DECK HEIGHT: 25"
FLOORING: Pine Lumber Floor
FRAME: Fabricated 1/4" Diamond Plate
CROSSMEMBERS: 3" Channel (3.50 lbs/ft) 16" Spacing
D-RINGS: 2 - D-Rings In Between Fenders
REAR
DECK: 3' Dovetail
RAMPS: Mountain Fold Flat Ramps
SIDES
STAKE POCKETS: 1,5/8" x 3,5/8" (ID) Stake Pockets (Spaced At 24")
FENDERS: 14ga. Diamond Plate Steel Fenders
RUNNING GEAR/TIRES
TYPE: Radial Tires
SIZE: ST235/75R17.5, Super Single
PLY: 18
RATING: 6,005 lbs
RIMS: 17.5" Black Mod Wheels
SUSPENSION
AXLE TYPE: 2 - 10k Dexter Electric Brake Oil Bath Torsion Axles
BOLT PATTERN: 8 On 6.5"
AXLE COUNT: 2
SUSPENSION TYPE: Torsion
AXLE WARRANTY: 5 Year Dexter Torsion Axle Warranty
ELECTRICAL AND LIGHTING/BATTERY AND CHARGING
WIRING HARNESS: All-Weather Wiring Harness (7-Way RV)
FRAME WIRING: Double Insulated Wiring Harness
LIGHTING
LIGHTS: DOT Approved Tecniq LED Lights
| Color | Ash Gray, Black |
| D-Rings | 2, 4, 6 |
| Year | 2026 |
| Fenders | Drive Over Fenders |
