Horizon HZ7 14' Dump Trailer - (2) 7K Axles
| Stock # | 15273 |
| Year | 2026 |
| Manufacturer | Horizon Trailers |
| Model Number | HZ7 14' x 83" BP |
| Color | Ash Gray/Navy Blue |
| Floor Length | 14' |
| Width | 83" |
| Side Wall Height | 2' |
| GVWR | 15,200 lbs |
| Unloaded Vehicle Weight | 4,890 lbs |
| Cargo Carrying Capacity | 10,370 lbs |
| Axle Capacity | 7,000 lbs |
| Location | Seminole |
Barcode:
3H7BD1423TR015273
Internal Reference:
15273
Standard Trailer Specs
DIMENSIONS - BUMPER PULL
LENGTH: 14'
SIDE HEIGHT: 2'
BED WIDTH: 83"
BED HEIGHT: 28"
WEIGHT RATINGS
GAWR: 7,000 lbs
GVWR BP: 15,200 lbs
TRAILER WIEGHT: 4,890 llbs
CARRYING CAPACITY: 10,370 lbs
FINISH
PAINT TYPE: Powdercoat
PREP: Steel Grit Blasted
TONGUE BP
TYPE: 8" I-Beam (13 lbs/ft)
LENGTH: 60"
SPARE: Weld On Spare Tire Mount
STANDARD COUPLER BP: Adjustable Demco EZ Latch 2-5/16" Bp Coupler (21,000 lbs)
FRONT JACK BP: 1 Side Wind Spring Loaded Drop Jack Leg (12,000 lbs)
TOOLBOX BP: Mega Lockable Toolbox Houses Battery & Pump (w/ Extra Storage)
SAFETY SYSTEM
BREAKAWAY SYSTEM: 2382 Brightway Group Electric Breakaway Kit
SAFETY CHAINS: 3/8" Grade 70 Safety Chain w/Clevis Hook (2 each)
CHASSIS
FRAME MAIN FRAME: 8" I-Beam (13 lbs/ft)
STEPS: Side Step On Both Sides
BED
BED WIDTH: 83"
BED HEIGHT: 28"
FLOORING: 7ga. Floor
FRAME: 5" x 5" x 5/16" Angle Iron (10.3 lbs/ft)
CROSSMEMBERS: 3" Channel (3.50 lbs/ft) 16" Spacing
D-RINGS: 4 D Rings Welded Inside Box
DUMP ANGLE: 39° - 49°
REAR
GATE: 2 Way Door
RAMPS: Ramp Pockets w/2 - 6' 4" Heavy Duty Slide In 4" Channel Ramps (5,000 lbs each)
REAR STANDS: Pair Of Rear Stabilizer Stands
SIDES
HEIGHT: 2'
THICKNESS: 10ga.
TYPE: Rounded Steel
TOP RAIL: 3" x 5" x 11ga. Tubing
STAKE POCKETS: 1,5/8" x 3,5/8" (ID) Stake Pockets
HOOKS: 3/8" Round "D" Hooks
FENDERS: 12ga. Diamond Plate Steel Fenders
SAFETY
TARP: Manual Tarp Kit
LIFT SYSTEM/HYDRAULICS
SYSTEM: Hydraulic - Power Up / Power Down
PUMP: KTI 12V Hydraulic Pump
CONTROLLER: 14' Control Cable
CYLINDER: 6" x 21" Single Push Cylinder
HOIST CAPACITY: 20,000 lbs
RUNNING GEAR/TIRES
TYPE: Radial Tires
SIZE: ST235/80R16
PLY: 10
RATING: 3,520 lbs
RIMS: 16" Black Mod Wheels
SUSPENSION
AXLE TYPE: 2 - 7k Dexter Electric Brake EZ Lube Spring Axles
BOLT PATTERN: 8 On 6.5"
AXLE COUNT: 2
SUSPENSION TYPE: Spring
AXLE WARRANTY: 5 Year Dexter Spring Axle Warranty
BATTERY AND CHARGING
BATTERY: 1 - Interstate 27 Deep Cycle Battery
CHARGING SYSTEM: 110V Integrated Trickle Charger
WIRING HARNESS: All-Weather Wiring Harness (7-Way RV)
FRAME WIRING: Double Insulated Wiring Harness
LIGHTING
LIGHTS: DOT Approved Tecniq LED Lights
SAFETY
REFLECTIVE TAPE: 3M Dot Compliant Reflective Tape
