Horizon EWZ 40' Gooseneck Driveover Fender Equipment Trailer (36'+4') - (3) 7K Axles
| Stock # | 12114 |
| Year | 2026 |
| Manufacturer | Horizon Trailers |
| Model Number | EWZ 40' x 102" GN |
| Color | Ash Gray |
| Floor Length | 40' |
| Width | 102" |
| GVWR | 21,000 lbs |
| Unloaded Vehicle Weight | 7,410 lbs |
| Cargo Carrying Capacity | 13,590 lbs |
| Axle Capacity | 7,000 lbs |
| Location | Seminole |
Barcode:
3H7GU4025TR015126
Internal Reference:
15126
TRAILER SPECS
LENGTH: 40’
DECK WIDTH: 102”
WEIGHT RATING
GAWR: 7,000 LBS
GVWR: 21,000 LBS
UNLOADED VEHICLE WEIGHT: 7,410 LBS
CARGO CARRYING CAPACITY: 13,590 LBS
FINISH
PAINT TYPE: POWDERCOAT
PREP: STEEL GRIT BLASTED
WARRANTY
AXLE WARRANTY: 5 YEAR DEXTER SPRING AXLE WARRANTY
TRAILER WARRANTY: 3 YEAR FRAME / 1 YEAR PARTS WARRANTY
TONGUE
TOUNGE TYPE: 10" ENGINEERED I-BEAM
LENGTH: 98" (FROM BEHIND RISER)
HEIGHT: 70" (FROM UNDERNEATH NECK]
SPARE: WELD ON SPARE TIRE MOUNT
STORAGE BEHIND NECK: STORAGE BOX / WINCH READY
COUPLER
STANDARD COUPLER: ADJUSTABLE 2-5/16" GN COUPLER [30,000 LBS]
JACKS
FRONT JACKS: 2 SIDE WIND SPRING-LOADED DROP JACK LEGS (12,000 LBS)
TOOLBOX: MEGA LOCKABLE TOOLBOX
SAFETY
SAFETY CHAINS: 3/8" GRADE 70 SAFETY CHAIN W/CLEVIS HOOK [2 EACH]
CHASSIS/FRAME
MAIN FRAME: 10" I-BEAM [15 LBS/FT] W/ 4" X 4" ANGLE IRON BRIDGE
TORQUE TUBE30' AND UP ONLY: 4,1/2" TUBE
DECK/BED
REAR OF DECK: 4' DOVETAIL
DECK FRAME: 3/16" DIAMOND PLATE
FLOORING: PINE LUMBER FLOOR
CROSSMEMBERS: 3" CHANNEL (3.50 LBS/FT] 16" SPACING
DECK HEIGHT: 30”
DECK WIDTH: 102”
WIDTH BETWEEN FENDERS: 83”
D-RINGS: 2 D-RINGS IN BETWEEN FENDERS
BOLT ON SWIVEL D- RINGS TIE DOWN SLOTS: 2- FLUSH MOUNT GALVANIZED SWIVEL D-RINGS FRONT OF TRAILER SLOTS FOR LATCH ON TIE DOWN FITTINGS ALONG SIDES OF DECK
SIDES
RUB RAIL: 2" X 3/8" RUB RAIL
STAKE POCKETS: 1,5/8" X 3,5/8" (ID] STAKE POCKETS (SPACED AT 24"]
SPOOLS: 2" X 10GA. PIPE SPOOLS (SPACED AT 24"]
FENDERS: 3/16" DIAMOND PLATE DRIVE OVER FENDERS
REAR
RAMPS: RAMP POCKETS W/ 5' 6" LONG HEAVY-DUTY SLIDE IN 4" CHANNEL RAMPS (7,000 LBS WHEEL RATING EACH ONLY OVER AREA OF 12" OR MORE)
RUNNING GEAR/TIRES
TYPE: RADIAL TIRES
SIZE: ST235/85R16
PLY: 10
RATING: 3,520 LBS
RIMS: 16" BLACK MOD WHEELS
SUSPENSION
AXLE TYPE: 7K DEXTER ELECTRIC BRAKE AUTO ADJUST EZ LUBE SPRING AXLES
BOLT PATTERN: 8 ON 6.5"
AXLE COUNT: 3
SUSPENSION TYPE: SPRING
AXLE WARRANTY: 5 YEAR DEXTER SPRING AXLE WARRANTY
ELECTRICAL AND LIGHTING/BATTERY AND CHARGING
BREAKAWAY SYSTEM: 2382 BRIGHTWAY GROUP ELECTRIC BREAKAWAY KIT
WIRING HARNESS: ALL-WEATHER WIRING HARNESS (7-WAY RV]
FRAME WIRING: DOUBLE INSULATED WIRING HARNESS
LIGHTING
LIGHTS: DOT APPROVED TECNIQ LED LIGHTS
SAFETY
REFLECTIVE TAPE: 3M DOT COMPLIANT REFLECTIVE TAPE
