Horizon FFT 24' Deck Over Full Tilt Trailer 7K
| Stock # | 12020 |
| Year | 2026 |
| Manufacturer | Horizon Trailers |
| Model Number | FFT 24' x 102" BP |
| Color | Black |
| Floor Length | 24' |
| Width | 102" |
| GVWR | 15,200 lbs |
| Axle Capacity | 7,000 lbs |
| Location | Springdale, AR |
Barcode:
3H7BF2423TR012020
Internal Reference:
12020
Standard Trailer Specs
DIMENSIONS
LENGTH: 24’
DECK HEIGHT: 36 ”
DECK WIDTH: 102”
WEIGHT RATING
GAWR: 7,000 LBS
GVWR: 15,200 LBS
FINISH
PAINT TYPE: POWDERCOAT
PREP: STEEL GRIT BLASTED
WARRANTY
AXLE WARRANTY: 6 YEAR LIPPERT SPRING AXLE WARRANTY
TRAILER WARRANTY: 3 YEAR FRAME/1 YEAR PARTS WARRANTY
TONGUE
TONGUE TYPE: NECKBOSS 10" ENGINEERED I-BEAM
LENGTH: 83"
SPARE: WELD ON SPARE TIRE MOUNT
COUPLER
STANDARD COUPLER: ADJUSTABLE AUTO LATCH 2-5/16" BP COUPLER (17,000 LBS)
JACKS
FRONT JACK: 2 SIDE WIND SPRING LOADED DROP JACK LEGS (12,000 LBS]
TOOLBOX
TOOLBOX: MEGA BOX LOCKABLE TOOLBOX
SAFETY
SAFETY CHAINS: 3/8" GRADE 70 SAFETY CHAIN W/CLEVIS HOOK [2 EACH]
FRAME
MAIN FRAME: 12" I-BEAM (14 LBS/FT]
SIDE
LEFT SIDE: LOCKABLE TOOLBOX (HOUSES BATTERIES AND PUMP)
DECK/BED
REAR OF DECK: 24' HYDRAULIC TILT DECK
DECK FRAME: 2" X 5" X 11GA. TUBING BED FRAME
FLOORING: PINE LUMBER FLOOR
CROSSMEMBERS: 3" CHANNEL [3.50 LBS/FT] 16" SPACING
DECK HEIGHT: 36”
DECK WIDTH: 102”
WINCH PLATE: WINCH PLATE ON DECK
TILT: 18 DEGREE
SIDES
RUB RAIL: 2" X 3/8" RUB RAIL
STAKE POCKETS: 1,5/8" X 3,5/8" (ID] STAKE POCKETS (SPACED AT 24")
SPOOLS: 2" X 10GA. PIPE SPOOLS (SPACED AT 24")
SIDES: SLIDE IN SIDE STEP ON BOTH SIDES
LIFT SYSTEM/HYDRAULICS
SYSTEM: 2 BUTTON HYDRAULIC - POWER UP / POWER DOWN
PUMP: KTI 12V HYDRAULIC PUMP
CONTROLLER: 14' CONTROL CABLE
WIRELESS CONTROLLER: TUFF WIRELESS 2 BUTTON WIRELESS REMOTE
DECK LIFT
LIFT CYLINDER: HOIST W/ 6" X 21" SINGLE PUSH CYLINDER (20,000 LBS)
RUNNING GEAR/TIRES
TYPE: RADIAL TIRES
SIZE: ST235/80 R16
PLY: 14
RATING: 4,025 LBS
RIMS: 16" BLACK MOD WHEELS
SUSPENSION
AXLE TYPE: 7K LIPPERT ELECTRIC BRAKE AUTO ADJUST DUAL OIL BATH SPRING AXLES
BOLT PATTERN: 8 ON 6.5"
AXLE COUNT: 2
SUSPENSION TYPE: SPRING
AXLE WARRANTY: 6 YEAR LIPPERT SPRING AXLE WARRANTY
ELECTRICAL AND LIGHTING/BATTERY AND CHARGING
BATTERY: 2 - INTERSTATE 27 DEEP CYCLE BATTERIES
WIRING HARNESS: ALL-WEATHER WIRING HARNESS (7-WAY RV)
FRAME WIRING: DOUBLE INSULATED WIRING HARNESS
LIGHTING
LIGHTS: DOT APPROVED TECNIQ LED LIGHTS
SAFETY
REFLECTIVE TAPE: 3M DOT COMPLIANT REFLECTIVE TAPE
