Horizon FTZ 24' Deck Over Equipment Trailer 7K (19'+5')
| Stock # | 11327 |
| Year | 2026 |
| Manufacturer | Horizon Trailers |
| Model Number | FTZ 24' x 102" BP |
| Color | Black |
| Floor Length | 24' |
| Width | 102" |
| GVWR | 15,200 lbs |
| Axle Capacity | 7,000 lbs |
| Location | Springdale, AR |
Barcode:
3H7BF2422TR011327
Internal Reference:
11327
Standard Trailer Specs
TRAILER SPECS/DIMENSIONS:
LENGTH: 24'
DECK WIDTH: 102"
DECK HEIGHT: 34"
WEIGHT RATINGS
GAWR: 7,000 lbs
GVWR: 15,200 lbs
FINISH
PAINT TYPE: Powdercoat
PREP: Steel Grit Blasted
WARRANTY
AXLE WARRANTY: 6 Year Lippert Torsion Axle Warranty
TRAILER WARRANTY: Three (3) Year Frame/One (1) Year Parts Warranty
TONGUE
TYPE: NECKBOSS 10" Engineered I-Beam
LENGTH: 83"
SPARE: Weld On Spare Tire Mount
COUPLER
STANDARD COUPLER : Adjustable Auto Latch 2-5/16" BP Coupler (17,000 lbs)
JACK
FRONT JACK : 2 Side Wind Spring Loaded Drop Leg Jacks (12,000 lbs)
TOOLBOX
TOOLBOX : Mega Lockable Toolbox Bp
SAFETY SYSTEM
BREAKAWAY SYSTEM: 2382 Brightway Group Electric Breakaway Kit
SAFETY CHAINS: 3/8" Grade 70 Safety Chain w/Clevis Hook (2 each)
CHASSIS/FRAME
MAIN FRAME: 12" I-Beam (14 lbs/ft)
DECK/BED
DECK WIDTH: 102"
DECK HEIGHT: 34"
FLOORING: Pine Lumber Floor
CROSSMEMBERS: 3" Channel (3.50 lbs/ft) 16" Spacing
RUB RAIL: 2" x 3/8" Rub Rail
STAKE POCKETS: 1,5/8" x 3,5/8" (ID) Stake Pockets (Spaced at 24")
SPOOLS: 2" x 10GA. Pipe Spools (Spaced at 24")
REAR
DECK: 5' Dovetail
RAMPS: Flip Over Mountain Ramps
RUNNING GEAR/TIRES
TYPE: Radial Tires
SIZE: ST235/80 R16
PLY: 14
RATING: 4,025 lbs
RIMS: 16" Black Mod Wheels
SUSPENSION
AXLE TYPE: 2 - 7k Lippert Electric Brake Auto adjust EZ Lube Spring Axles
BOLT PATTERN: 8 On 6.5"
AXLE COUNT: 2
SUSPENSION TYPE: Spring
AXLE WARRANTY: 6 Year Lippert Torsion Axle Warranty
ELECTRICAL AND LIGHTING/BATTERY AND CHARGING
WIRING HARNESS: All-Weather Wiring Harness (7-Way RV)
FRAME WIRING: Double Insulated Wiring Harness
LIGHTING
LIGHTS: DOT Approved Tecniq LED Lights
