Horizon HZ5 10' Dump Trailer 5.2K
| Stock # | 09723 |
| Year | 2025 |
| Manufacturer | Horizon Trailers |
| Model Number | HZ5 10' x 60" |
| Floor Length | 10' |
| Width | 60" |
| Side Height | 2' |
| Color | Black/Orange |
| GVWR | 11,300 LBS |
| Unloaded Vehicle Weight | 2,420 lbs |
| Cargo Carrying Capacity | 8,880 lbs |
| Axle Capacity | 5,200 lbs |
| Location | Springdale, AR |
Barcode:
3H7BD1025SR009723
Internal Reference:
09723
Standard Trailer Specs
DIMENSIONS
LENGTH: 12'
SIDE HEIGHT: 2'
BED WIDTH: 77"
BED HEIGHT: 24"
WEIGHT RATING
GAWR: 5,200 LBS
GVWR: 11,300 LBS
FINISH
PAINT TYPE: POWDERCOAT
PREP: STEEL GRIT BLASTED
STYLE: 2 TONE COLORS AVAILABLE, CHASSIS / DUMP
WARRANTY
AXLE WARRANTY: 6 YEAR LIPPERT SPRING AXLE WARRANTY
TRAILER WARRANTY: 3 YEAR FRAME / 1 YEAR PARTS WARRANTY
TONGUE
TYPE: 6" I-BEAM (8.5 LBS/FT]
LENGTH: 50"
COUPLER
STANDARD COUPLER: ADJUSTABLE AUTO LATCH 2,5/16" BP COUPLER (17,000 LBS)
JACKS
FRONT JACK: 1 SIDE WIND DROP JACK LEG (7000 LBS)
TOOLBOX
TOOLBOX: LOCKABLE TOOLBOX BP (HOUSES BATTERY AND PUMP]
SAFETY SYSTEM
SAFETY CHAINS: 1/4" GRADE 70 SAFETY CHAIN W/CLEVIS HOOK (2 EACH)
CHASSIS/FRAME
MAIN FRAME: 6" I-BEAM (8.5 LBS/FT]
DUMP/BED
BED WIDTH: 77'
BED HEIGHT: 24'
FLOORING: 9GA. STEEL BED
FRAME: 1,1/2" X 3" X 11GA. TUBING
CROSSMEMBERS: 3" CHANNEL (3.50 LBS/FT] 16" SPACING
D-RINGS: 4 D-RINGS WELDED INSIDE BOX
DUMP ANGLE: 45°
REAR
GATE: 3 WAY DOOR - SPREADER GATE
RAMPS: RAMP POCKETS W/5' LONG SLIDE IN 3" CHANNEL RAMPS CHANNEL RAMPS (4,000 LBS WHEEL RATING EACH
ONLY OVER AREA OF 12" OR MORE)
SIDES
HEIGHT: 2’
THICKNESS: 12GA
TYPE: ROUNDED STEEL
TOP RAIL: 2" X 3" X 11GA. TUBING
STAKE POCKETS: 1,5/8" X 3,5/8" (ID] STAKE POCKETS
HOOKS: 3/8" ROUND "J" HOOKS
FENDERS: 14GA DIAMOND PLATE STEEL FENDERS
SPARE: WELD ON SPARE TIRE MOUNT
SAFETY
TARP: MANUAL TARP KIT
LIFT SYSTEM/HYDRAULICS
SYSTEM: 2 BUTTON HYDRAULIC - POWER UP / POWER DOWN
PUMP: KTI 12V HYDRAULIC PUMP
CONTROLLER: 14' CONTROL CABLE
DUMP LIFT
LIFT CYLINDER: HOIST W/ 5" X 16" SINGLE PUSH CYLINDER (15,000 LBS)
RUNNING GEAR/TIRES
TYPE: RADIAL TIRES
SIZE: ST225/75R15
PLY: 10
RATING: 2,830 LBS
RIMS: 15" BLACK MOD WHEELS
SUSPENSION
AXLE TYPE: 5.2K LIPPERT ELECTRIC BRAKE AUTO ADJUST EZ LUBE SPRING AXLES
BOLT PATTERN: 6 ON 5.5"
AXLE COUNT: 2
SUSPENSION TYPE: SPRING
AXLE WARRANTY: 6 YEAR LIPPERT SPRING AXLE WARRANTY
ELECTRICAL AND LIGHTING/BATTERY AND CHARGING
BATTERY: 1 - INTERSTATE 27 DEEP CYCLE BATTERY
CHARGING SYSTEM: 110V INTEGRATED TRICKLE CHARGER
WIRING HARNESS: ALL-WEATHER WIRING HARNESS (7-WAY RV)
FRAME WIRING: DOUBLE INSULATED WIRING HARNESS
LIGHTING
LIGHTS: DOT APPROVED TECNIQ LED LIGHTS
SAFETY
REFLECTIVE TAPE: 3M DOT COMPLIANT REFLECTIVE TAPE
